2-2. Model: AOYG14KMTA
Unit: mm
Airflow
184
120
37
179399
Bottom view Side view (Bulb part)
580 109
799 68 29016
33 30
19
330
542
20
Pitch of bolts
for installation
Pitch of bolts for installation
Top view
Side viewSide view
Front view
Drain port Ø42
4-
M1
0 hole
DESIGN & TECHNICAL MANUAL
- 42 -
OUTDOOR UNIT
AOYG07-14KMTA
