Fujitsu ASYG30LMTA User Manual

- 34 -
WALL MOUNTED ASYG30, 36LMTA
 Forced thermostat off function
 Control output function
 Operation/Stop status
The output is low when the unit is stopped.
Function
setting /
Rotary SW on
External input and
output PCB
External input Input signal Command
60-00 / 2
60-09 / B
60-10 / C
External input and output
PCB
CN313
Off → On
Thermostat
off
On → Off
Normal
operation
Function
setting /
Rotary SW on
External input and
output PCB
External output
Output
signal
Command
60-00 / 1, 2 Output of indoor unit CN3
Low → High Operation
High → Low Stop
60-00 / 1
External input and output
PCB
CN310
Off → On Operation
On → Off Stop
On
Off
On
Off
Compressor
Room temp.
Set temp.
Input
Operation
Stop
High
Low
CN3
On
Off
CN310
Indoor unit
