Fujitsu ASYG30LMTA User Manual

- 33 -
WALL MOUNTED ASYG30, 36LMTA
 When function setting is "Operation/Stop" mode 2
• In the case of "Edge" input
• In the case of "Pulse" input
NOTES:
• When "Operation/Stop" mode 2 function is used with forming a remote controller group, connect
the same equipment to each indoor unit within the group.
• This function is invalid when function setting 96 is set to “02” (Secondary unit).
Function
setting /
Rotary SW on
External input and
output PCB
External input Input signal Command
46-03
- Input of indoor unit CN2
Off → On Operation
On → Off
Stop (R.C.
disabled)
60-00 / 1
External input and
output PCB
CN313
Off → On Operation
On → Off
Stop (R.C.
disabled)
Function
setting /
Rotary SW on
External input and
output PCB
External input Input signal Command
46-03 60-00 / 1
External input and
output PCB
CN313 Pulse Operation
CN314 Pulse
Stop (R.C.
disabled)
On
CN313
Off
Operation
Indoor unit
Stop
(R.C. disabled)
Remote contoller
On OnOff
On
On
Off
Operation
Stop
Remote controller
On
Off
Indoor unit
CN313
CN314
(R.C. disabled)
Off
On
