Fujitsu ASYG36LMTA Installation Manual

En-2
2.2. Special tools for R410A
Tool name Change from R22 to R410A
Gauge manifold
PressureishighandcannotbemeasuredwithaR22
gauge.Topreventerroneousmixingofotherrefrigerants,
thediameterofeachporthasbeenchanged.
Itisrecommendedtousegaugewithseals-0.1to5.3MPa
(-1to53bar)forhighpressure.
-0.1to3.8MPa(-1to38bar)forlowpressure.
Charge hose
Toincreasepressureresistance,thehosematerialandbase
sizewerechanged.(R410A)
Vacuum pump
A conventionalvacuumpumpcan beused byinstalling a
vacuumpumpadapter.
(Useofavacuumpumpwithaseriesmotorisprohibited.)
Gas leakage detector SpecialgasleakagedetectorforHFCrefrigerantR410A.
Copper pipes
Itisnecessarytouseseamlesscopperpipesanditisdesirablethattheamountofresidual
oilislessthan40 mg/10m.Donot usecopperpipeshaving acollapsed,deformedor
discoloredportion (especially onthe interior surface). Otherwise,the expansion valueor
capillarytubemaybecomeblockedwithcontaminants.
AsanairconditionerusingR410AincurspressurehigherthanwhenusingR22,itisneces-
sary
tochooseadequatematerials.
WARNING
•Donotusetheexisting(forR22)pipingandarenuts.
Iftheexistingmaterialsareused,thepressureinsidetherefrigerantcyclewillriseand
causefailure,injury,etc.(UsethespecialR410Amaterials.)
•Use(rellorreplacewith)speciedrefrigerant(R410A)only.Useofunspeciedrefrig-
erantcancauseproductmalfunction,burst,orinjury.
•Donotmixanygasorimpuritiesexceptspeciedrefrigerant(R410A).Inowofairor
applicationofunspeciedmaterialmakestheinternalpressureoftherefrigerantcycle
toohigh,andmaycauseproductmalfunction,burstofpiping,orinjury.
WARNING
•Forappropriateworkingoftheairconditioner,installitaswritteninthismanual.
•Toconnectindoorunitandoutdoorunit,useairconditionerpipingandcablesavailable
throughyourlocaldistributor.Thismanualdescribesproperconnectionsusingsuch
installationset.
•Donotturnonthepoweruntilallworkhasbeencompleted.
CAUTION
Thismanualdescribeshowtoinstalltheindoorunitonly.Toinstalltheoutdoorunit,(if
any),refertotheinstallationmanualincludedineachproduct.
• Becarefulnottoscratchtheairconditionerwhenhandlingit.
• Afterinstallation,explaincorrectoperationtothecustomer,usingtheoperatingmanual.
2.3. Accessories
Thefollowinginstallationaccessoriesaresupplied.Usethemasrequired.
Name and Shape Q’ty Name and Shape Q’ty
OperatingManual
1
Clothtape
1
InstallationManual
(This
manual)
1
Tappingscrew(Large)
8
Wallhookbracket
1
Tappingscrew(Small)
2
Remotecontroller
1
Aircleaningfilter
2
Battery
2
Filterholders
2
Remotecontrollerholder
1
Drainhoseinsulation
1
Thefollowingitemsarenecessarytoinstallthisairconditioner.(Theitemsarenotinclud-
edwiththeairconditionerandmustbepurchasedseparately.)
Name Q’ty Name Q’ty
Connectionpipeassembly 1 Wallcap 1
Connectioncable(4-conductor) 1 Saddle 1set
Wallpipe 1 Drainhose 1
Decorativetape 1 Tappingscrews 1set
Vinyltape 1 Sealant 1
2.4. Optional parts
Refertoeachinstallationmanualforthemethodofinstallingoptionalparts.
Parts name Model name Application
WiredRemoteController* UTY-RVN*M Forairconditioneroperation
WiredRemoteController** UTY-RNR*Z1 Forairconditioneroperation
WiredRemoteController** UTY-RLR* Forairconditioneroperation
SimpleRemoteController* UTY-RSN*M Forairconditioneroperation
Communicationkit UTY-XWNX Fortheinstallationofoptionalparts
Communicationkit UTY-TWRX Fortheinstallationofoptionalparts
Externalconnectkit UTY-XWZX Forcontrolinput/outputport
ExternalinputandoutputPCB*** UTY-GXXB Forconnectingexternaldevices
PCBkit UTY-XCSXZ1 Fortheinstallationofoptionalparts
*Optionalcommunicationkit(UTY-XWNX)isnecessaryfortheinstallation.
**Optionalcommunicationkit(UTY-TWRX)isnecessaryfortheinstallation.
***OptionalPCBkit(UTY-XCSXZ1)isnecessaryfortheinstallation.
3. GENERAL SPECIFICATION
ThisINSTALLATIONMANUALbrieyoutlineswhereandhowtoinstalltheairconditioningsystem.
Pleasereadover theentireset ofinstructionsfor theindoorand outdoorunitsand makesureall
accessorypartslistedarewiththesystembeforebeginning.
3.1. Type of copper pipe and insulation material
CAUTION
Refertotheinstallationmanualoftheoutdoorunitfordescriptionofthelengthof
connectingpipeorfordifferenceofitselevation.
Gas pipe size (thickness) [mm] Liquid pipe size (thickness) [mm]
Ø
15.88(5/8in.)
Ø
9.52(3/8in.)
CAUTION
•Wrapheatinsulationaroundbothofthegaspipeandtheliquidpipe.
Noheat-insulationworkorincorrectheat-insulationworkmaycausewaterleaks.
•Inareversecyclemodel,useheatinsulationwithheatresistanceabove120°C.
•Ifexpectedhumidityoftheinstallationlocationofrefrigerantpipesishigherthan70
%,wraptheheatinsulationaroundtherefrigerantpipes.
Iftheexpectedhumidityisbetween70%and80%,useheatinsulationthathas
thicknessof15mmormore.
Iftheexpectedhumidityishigherthan80%,useheatinsulationthathasthickness
of20mmormore.
•Usingofthinnerheatinsulationthanspeciedabovemaycauseacondensationon
thesurfaceoftheinsulation.
•Useheatinsulationwiththermalconductivityof0.045W/(
m•K )orless,at20 °C .
3.2. Additional materials required for installation
A.Refrigeration(armored)tape
B.Insulatedstaplesorclampsforconnectingwire(Seeyourlocalelectricalcodes.)
C.Putty
D.Refrigerationlubricant
E.Clampsorsaddlestosecurerefrigerantpiping
4. ELECTRICAL REQUIREMENT
Theindoorunitispoweredfromtheoutdoorunit.Donotpowerindoorunitfromseparate
powersource.
WARNING
Standardforelectricalwiringandequipmentdiffersineachcountryorregion.Beforeyou
startelectricalworking,conrmrelatedregulations,codes,orstandards.
Cable Conductor size [
mm
2
] Type Remarks
Connectioncable 1.5 Type60245IEC57
3cable+Earth(Ground),
1Ø230V
Max.CableLength:Limit voltagedroptoless than2%.Increase cablegaugeifvoltage
dropis2%ormore.
