Fujitsu ASYG36LMTA Installation Manual

En-6
(2)Removethetappingscrewandwhilemindingthecableclamphook,removethecable
clamp.
Screw
Cableclamp
Cableclamp
Hook
(3)Connecttheendoftheconnectioncablefullyintotheterminalblock.
123
25mm
65mm
Earth(ground)wire
7.3. How to connect wiring to the terminals
Cautionwhenwiringcable
Tostripofftheinsulationofaleadwire,alwaysuseaspecialtoolsuchasawirestripper.
Ifthereisnospecialtool,carefullystripofftheinsulationbyusingaknifeorotherutensil.
(1) Usering terminalswith insulating sleevesas shown inthe gure toconnect to the
terminalblock.
(2) Securelyclamptheringterminalstothewiresbyusinganappropriatetoolsothatthe
wiresdonotcomeloose.
Strip:10mm
Ringterminal
Sleeve
(3) Connectspeciedwiressecurely,andfastenthemsothatthereisnostressappliedon
theterminals.
(4) Useascrewdriverwithanappropriatebitsizetotightentheterminalscrews.Usingof
screwdriverwithinappropriatebitsizewilldamagethescrewheads,andthescrews
willnotbetightenedproperly.
(5) Donotovertightentheterminalscrews.Otherwise,thescrewsmaybreak.
Screwwithspecialwasher
Wire
Ringterminal
Terminalblocks
Wire
Screwwithspecialwasher
Ringterminal
(6) Seethetablefortheterminalscrewtighteningtorques.
Tighteningtorque[N·m(kgf·cm)]
M4screw 1.2to1.8(12to18)
CAUTION
•Matchtheterminalblocknumbersandconnectioncablecolorswiththoseofthe
outdoorunit.Incorrectwiringmaycauseare.
•Connecttheconnectioncablesrmlytotheterminalblock.Imperfectinstallationmay
causeare.
•Whenxingtheconnectioncablewiththecableclamp,alwaysfastenthecableatthe
plasticjacketportion,butnotattheinsulatorportion.Iftheinsulatorischafed,electric
leakagemayoccur.
•Alwaysconnecttheearth(ground)wire.Improperearthing(grounding)workcan
causeelectricshocks.
•Donotusetheearth(ground)screwfortheindoorunittotheoutdoorunitunlessitis
specied.
8. FINISHING
(1) Insulatebetweenpipes.
• Insulatesuctionanddischargepipesseparately.
• Forrear,right,andbottompiping,overlaptheconnectionpipeheatinsulationand
indoorunitpipeheatinsulationandbindthemwithvinyltapesothatthereisnogap.
(2) Temporarilyfastentheconnectioncablealongtheconnectionpipewithvinyltape.
(Wraptoabout1/3thewidthofthetapefromthebottomofthepipesothatwater
doesnotenter.)
(3) Fastentheconnectionpipetotheoutsidewallwithasaddle,etc.
(4) Fillthegapbetweentheoutsidewallpipeholeandthepipewithsealersothatrain
waterandwindcannotblowin.
(5) Fastenthedrainhosetotheoutsidewall,etc.
*Locallypurchased
Pipe
Saddle*
Outsidewallcap*
Sealerputty*
(Outdoors)
Wall
Overlaptheinsulation
Vinyltape
Wrapwithclothtape
Clothtape
Drainhose
Pipe
Connectionpipe
(heatinsulation)
Indoorunitpipe
(heatinsulation)
Bindthepipestogether
sothatthereisnogap.
Drainhoseinsulationisused
whenthediameterofgaspipeis
Ø12.70ormore.
Buttconnectionpipe(heat
insulation)againsttheindoor
unitpipe(heatinsulation)and
wrapwithdrainhoseinsula-
tionsothatthereisnogap.
Checkthefollowing:
GOOD
Drainhose
Saddle
Liftedup Wave Endinwater
PROHIBITED
9387082050_IM.indb 6 12/10/2015 13:33:23
