10-37
2. FILTER removal
Remove the FILTER.
FILTER
Hook
(3 places)
3. CONTROL BOX COVER removal
Remove the 2 mounting boits.
Remove the CONTROL BOX COVER upward.
CONTROL BOX COVER
B
A
DETAIL A
(3 places)
DETAIL B
MOVE
