MODEL : AU*45LUAS / AO*45LJBYL
MODEL : AUT45LUAS / AOT45LJBYL
COOLING
HEATING
AFR 28.3
(°CDB)
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
-15 10.59 9.16 2.06 11.13 9.92 2.08 12.07 11.22 2.11 12.55 11.25 2.13 13.50 11.29 2.17 13.99 11.31 2.19 14.49 12.20 2.20
-10 12.64 10.01 2.45 12.97 10.90 2.46 13.63 11.68 2.49 13.95 11.60 2.51 14.57 11.38 2.53 14.86 11.25 2.54 15.12 12.01 2.55
0 11.59 9.12 3.05 11.86 9.99 3.07 12.42 10.75 3.11 12.69 10.66 3.13 13.23 10.47 3.15 13.48 10.37 3.16 13.73 11.17 3.17
10 11.02 8.87 3.36 11.30 9.75 3.38 11.85 10.53 3.42 12.13 10.45 3.43 12.66 10.27 3.46 12.94 10.19 3.48 13.19 10.99 3.49
20 13.27 9.87 3.53 13.69 10.78 3.53 14.54 11.66 3.52 14.99 11.62 3.52 15.91 11.56 3.50 16.33 11.52 3.48 16.78 12.37 3.47
30 11.71 9.18 4.24 12.12 10.10 4.25 12.95 10.96 4.26 13.37 10.93 4.27 14.23 10.83 4.27 14.66 10.78 4.27 15.06 11.62 4.27
35 11.68 9.17 5.13 12.09 10.09 5.16 12.86 10.94 5.13 14.00 10.90 5.15 14.02 11.04 5.18 14.43 10.69 5.13 14.82 11.54 5.15
40 10.12 8.34 5.00 10.37 9.18 5.00 10.97 9.99 5.00 11.34 10.00 5.00 12.55 9.91 5.00 12.29 9.90 5.00 12.63 10.73 5.00
43 9.28 7.98 5.00 9.62 8.87 5.00 10.26 9.70 5.00 10.63 9.67 5.00 11.18 9.54 5.00 11.51 9.49 5.00 11.84 10.31 5.00
32°CDB
21°CWB
22°CWB
23°CWB
21°CDB
23°CDB
15°CWB
16°CWB
Outdoor temperature
Indoor temperature
26°CDB
27°CDB
29°CDB
18°CWB
19°CWB
30°CDB
AFR 28.3
(°CDB) (°CWB) TC PI TC PI TC PI TC PI TC PI TC PI TC PI
-15 -16 7.32 3.55 7.16 3.61 7.02 3.66 6.43 3.71 6.34 3.79 6.23 3.86 6.06 3.94
-10 -11 9.55 4.05 9.34 4.12 9.12 4.18 8.79 4.29 8.68 4.51 8.34 4.47 7.92 4.49
-4 -6 10.99 4.17 10.75 4.25 10.51 4.32 10.07 4.41 9.77 4.43 9.45 4.45 8.93 4.46
1 -1 12.66 4.41 12.33 4.42 12.00 4.45 11.42 4.45 10.98 4.42 10.63 4.44 10.03 4.44
7 6 16.57 4.60 16.07 4.60 16.00 4.60 14.96 4.60 14.36 4.60 13.71 4.60 12.86 4.44
12 10 17.48 4.60 16.96 4.60 16.42 4.60 15.73 4.60 15.07 4.40 14.53 4.44 13.59 4.20
18 13 18.28 4.40 17.90 4.60 17.34 4.40 16.53 4.40 15.98 4.20 15.37 4.20 14.34 4.00
20 15 18.01 4.20 17.53 4.20 17.15 4.20 16.36 4.20 15.66 4.00 15.12 4.00 14.17 4.00
24 17 17.50 4.00 17.01 4.00 16.62 4.00 15.82 4.00 15.11 4.00 14.61 4.00 13.62 4.00
Outdoor temperature
Indoor temperature
16°CDB
18°CDB
20°CDB
23°CDB
25°CDB
27°CDB
30°CDB
AFR: Air flow rate (m
3
/min)
TC : Total capacity (kW)
SHC: Sensible Heat capacity (kW)
PI : Power Input (kW)
AFR: Air flow rate (m
3
/min)
TC : Total capacity (kW)
SHC: Sensible Heat capacity (kW)
PI : Power Input (kW)
COOLING
HEATING
AFR 29.2
(°CDB) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
-15 10.06 8.42 2.04 10.59 9.16 2.06 11.13 9.92 2.08 12.07 11.22 2.11 12.55 11.25 2.13 13.50 11.29 2.17 13.99 11.31 2.19 14.49 12.20 2.20
-10 12.00 9.20 2.43 12.64 10.01 2.45 12.97 10.90 2.46 13.63 11.68 2.49 13.95 11.60 2.51 14.57 11.38 2.53 14.86 11.25 2.54 15.12 12.01 2.55
0 11.01 8.39 3.02 11.59 9.12 3.05 11.86 9.99 3.07 12.42 10.75 3.11 12.69 10.66 3.13 13.23 10.47 3.15 13.48 10.37 3.16 13.73 11.17 3.17
10 10.47 8.16 3.33 11.02 8.87 3.36 11.30 9.75 3.38 11.85 10.53 3.42 12.13 10.45 3.43 12.66 10.27 3.46 12.94 10.19 3.48 13.19 10.99 3.49
20 12.61 9.08 3.51 13.27 9.87 3.53 13.69 10.78 3.53 14.54 11.66 3.52 14.99 11.62 3.52 15.91 11.56 3.50 16.33 11.52 3.48 16.78 12.37 3.47
30 11.13 8.44 4.23 11.71 9.18 4.24 12.12 10.10 4.25 12.95 10.96 4.26 13.37 10.93 4.27 14.23 10.83 4.27 14.66 10.78 4.27 15.06 11.62 4.27
35 11.10 8.43 5.13 11.68 9.17 5.13 12.09 10.09 5.16 12.86 10.94 5.13 14.00 10.90 5.15 14.02 11.04 5.18 14.43 10.69 5.13 14.82 11.54 5.15
40 9.61 7.67 5.00 10.12 8.34 5.00 10.37 9.18 5.00 10.97 9.99 5.00 11.34 10.00 5.00 12.55 9.91 5.00 12.29 9.90 5.00 12.63 10.73 5.00
43 8.82 7.34 5.00 9.28 7.98 5.00 9.62 8.87 5.00 10.26 9.70 5.00 10.63 9.67 5.00 11.18 9.54 5.00 11.51 9.49 5.00 11.84 10.31 5.00
Outdoor temperature
26°CDB
15°CWB
16°CWB
12°CWB
29°CDB
18°CWB
19°CWB
21°CWB
22°CWB
23°CWB
30°CDB
21°CDB
23°CDB
18°CDB
Indoor temperature
32°CDB
27°CDB
AFR 29.2
(°CDB) (°CWB) TC PI TC PI TC PI TC PI TC PI TC PI TC PI
-15 -16 8.53 3.78 8.35 3.84 8.24 4.14 7.86 4.14 7.75 4.60 7.45 4.60 7.07 4.60
-10 -11 10.50 4.20 10.28 4.27 10.03 4.34 9.68 4.46 9.55 4.60 9.17 4.60 8.71 4.60
-4 -6 12.45 4.38 12.18 4.47 11.91 4.54 11.42 4.60 11.06 4.60 10.71 4.60 10.12 4.60
1 -1 14.35 4.60 13.97 4.60 13.59 4.60 12.94 4.60 12.45 4.60 12.04 4.60 11.36 4.60
7 6 16.74 4.60 16.24 4.60 16.00 4.60 15.12 4.60 14.50 4.60 13.85 4.60 12.99 4.60
12 10 17.66 4.60 17.13 4.60 16.59 4.60 15.89 4.60 15.22 4.60 14.68 4.60 13.73 4.60
18 13 18.47 4.60 18.08 4.60 17.52 4.60 16.70 4.60 16.15 4.60 15.52 4.60 14.48 4.60
20 15 18.20 4.60 17.71 4.60 17.33 4.60 16.53 4.60 15.82 4.60 15.28 4.60 14.32 4.60
24 17 17.50 4.60 17.01 4.60 16.62 4.60 15.82 4.60 15.11 4.60 14.61 4.60 13.62 4.60
30°CDB
Outdoor temperature
Indoor temperature
16°CDB
18°CDB
20°CDB
23°CDB
25°CDB
27°CDB
