Fujitsu AU*24LUAR - Page 96

08-05
MODEL : AUT54LUAS / AOT54LJBYL
AFR: Air flow rate (m
3
/min)
TC : Total capacity (kW)
SHC: Sensible Heat capacity (kW)
PI : Power Input (kW)
COOLING
HEATING
AFR 29.2
(°CDB) (°CWB) TC PI TC PI TC PI TC PI TC PI TC PI TC PI
-15 -16 8.79 4.27 8.61 4.34 8.49 4.68 8.10 4.68 8.00 5.20 7.68 5.20 7.29 5.20
-10 -11 10.83 4.74 10.60 4.83 10.34 4.91 9.98 5.04 9.85 5.20 9.46 5.20 8.98 5.20
-4 -6 12.84 4.96 12.56 5.05 12.28 5.14 11.78 5.20 11.40 5.20 11.04 5.20 10.44 5.20
1 -1 14.80 5.20 14.41 5.20 14.02 5.20 13.35 5.20 12.84 5.20 12.41 5.20 11.71 5.20
7 6 17.27 5.20 16.74 5.20 16.50 5.20 15.59 5.20 14.96 5.20 14.28 5.20 13.39 5.20
12 10 18.21 5.20 17.67 5.20 17.11 5.20 16.39 5.20 15.70 5.20 15.14 5.20 14.16 5.20
18 13 19.05 5.20 18.65 5.20 18.07 5.20 17.22 5.20 16.65 5.20 16.01 5.20 14.94 5.20
20 15 18.77 5.20 18.26 5.20 17.87 5.20 17.04 5.20 16.32 5.20 15.75 5.20 14.76 5.20
24 17 17.50 5.20 17.01 5.20 16.62 5.20 15.82 5.20 15.11 5.20 14.61 5.20 13.62 5.20
Outdoor temperature
Indoor temperature
16°CDB
18°CDB
20°CDB
23°CDB
25°CDB
27°CDB
30°CDB
AFR 29.2
(°CDB) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
-15 10.42 8.29 2.26 10.97 9.01 2.28 11.53 9.76 2.30 12.51 11.04 2.34 13.00 11.06 2.36 13.98 11.10 2.40 14.49 11.12 2.42 15.00 12.00 2.43
-10 12.43 9.05 2.68 13.09 9.84 2.71 13.43 10.72 2.72 14.12 11.49 2.76 14.45 11.41 2.78 15.09 11.19 2.80 15.39 11.06 2.81 15.66 11.81 2.82
0 11.40 8.25 3.34 12.00 8.97 3.38 12.29 9.82 3.40 12.86 10.58 3.44 13.14 10.48 3.47 13.71 10.30 3.49 13.96 10.20 3.50 14.22 10.98 3.51
10 10.84 8.03 3.68 11.41 8.72 3.72 11.70 9.59 3.74 12.27 10.36 3.79 12.56 10.28 3.80 13.11 10.10 3.83 13.40 10.02 3.85 13.66 10.81 3.86
20 13.06 8.93 3.90 13.75 9.70 3.91 14.18 10.60 3.91 15.06 11.46 3.90 15.52 11.43 3.89 16.47 11.37 3.87 16.91 11.33 3.85 17.38 12.16 3.84
30 11.53 8.30 4.68 12.13 9.02 4.69 12.55 9.93 4.70 13.41 10.78 4.72 13.84 10.75 4.73 14.74 10.66 4.73 15.18 10.60 4.73 15.59 11.43 4.73
35 11.50 8.29 5.70 12.10 9.01 5.70 12.53 9.92 5.70 13.32 10.76 5.70 14.50 10.72 5.70 14.52 10.86 5.70 14.95 10.52 5.70 15.35 11.35 5.70
40 9.95 7.54 5.15 10.48 8.20 5.15 10.74 9.03 5.15 11.36 9.82 5.15 11.75 9.83 5.15 13.00 9.75 5.15 12.73 9.74 5.15 13.08 10.56 5.15
43 9.13 7.22 5.15 9.61 7.84 5.15 9.97 8.72 5.15 10.63 9.54 5.15 11.01 9.51 5.15 11.58 9.39 5.15 11.93 9.34 5.15 12.26 10.14 5.15
21°CWB
22°CWB
23°CWB
Indoor temperature
27°CDB
29°CDB
32°CDB
15°CWB
16°CWB
18°CDB
12°CWB
19°CWB
30°CDB
Outdoor temperature
26°CDB
18°CWB
21°CDB
23°CDB
