PARTS LIST
When you order parts, please make a photocopy of this page
and fill the number of the parts in the “Order” column.
INDOOR UNIT
Ref.
No.
Description
AUT36ALA3W AUT36RLA3W
Ord.
Q’ty
34 Capacitor (Fan Motor) 9703306068 9703306068 9703306068 9703306068 9703306068 9703306068
47-1 Rubber (Discha. Pipe) 313194159807 313194159807 313194159807 313194159807 313194159807 313194159807
61 Decoration Plate 9362787000 9362787000 9362787000 9362787000 9362787000 9362787000
67 Rubber (Vibration Proof) 9362783002 9362783002 9362783002 9362783002 9362783002 9362783002
71 Grille Hook Holder 9362782005 9362782005 9362782005 9362782005 9362782005 9362782005
93 Filter 9362766005 9362766005 9362766005 9362766005 9362766005 9362766005
117-3 Hex. Nut w / Spring Washer 301721180114 301721180114 301721180114 301721180114 301721180114 301721180114
122 Louver Support Holder 9362799003 9362799003 9362799003 9362799003 9362799003 9362799003
127 Drain Hose 9362784009 9362784009 9362784009 9362784009 9362784009 9362784009
138 Separate Wall 9362737005 9362737005 9362737005 9362737005 9362737005 9362737005
143-1 Clamp NK-3N 313361274700 313361274700 313361274700 313361274700 313361274700 313361274700
143-3 Clamp NK-6N 9305657001 9305657001 9305657001 9305657001 9305657001 9305657001
146-1 Evaporator-A Assy 9363149005 9363149005 9363149005 9363149005 9363149005 9363149005
146-2 Evaporator-B Assy 9363150001 9363150001 9363150001 9363150001 9363150001 9363150001
155 Special Nut M6 9307615016 9307615016 9307615016 9307615016 9307615016 9307615016
160 Drain Pan Assy 9362804004 9362804004 9362804004 9362804004 9362804004 9362804004
164 Fan Motor Assy-IN 9600878019 9600878019 9600878019 9600878019 9600878019 9600878019
168 Cabinet-E 9362735001 9362735001 9362735001 9362735001 9362735001 9362735001
184-1 Thermo. Spring-A 313728262708 313728262708 313728262708 313728262708 313728262708 313728262708
187 Clamp No. 1219 313361271706 313361271706 313361271706 313361271706 313361271706 313361271706
195 Clamp SKB-100 313361275805 313361275805 313361275805 313361275805 313361275805 313361275805
196-2 Clamp SKB-150 313035356905 313035356905 313035356905 313035356905 313035356905 313035356905
197 Wind Guide Board 9363117004 9363117004 9363117004 9363117004 9363117004 9363117004
210 Main Relay 9356781007 9356781007 9356781007 9356781007 9356781007 9356781007
223 Control Box 9362762007 9362762007 9362762007 9362762007 9362762007 9362762007
226 Motor Gear 9362764001 9362764001 9362764001 9362764001 9362764001 9362764001
234 Thermistor Assy-Room 9703299025 9703299025 9703299025 9703299025 9703299025 9703299025
235 Thermistor Assy-Pipe 9703297014 9703297014 9703297014 9703297014 9703297014 9703297014
236 Controller PCB Assy 9700637011 9700637028 9700637035 9700637042 9700637059 9700637066
240 Remote Control Unit 9703173042 9703173035 9703173042 9703173035 9703173042 9703173035
244 Pipe Cover 9362748001 9362748001 9362748001 9362748001 9362748001 9362748001
245 Cable Clamp 313714181904 313714181904 313714181904 313714181904 313714181904 313714181904
337-1 Reinforcement (Eva.)-A 9362749008 9362749008 9362749008 9362749008 9362749008 9362749008
337-2 Reinforcement (Eva.)-B 9362750004 9362750004 9362750004 9362750004 9362750004 9362750004
338 Motor Holder 9362765008 9362765008 9362765008 9362765008 9362765008 9362765008
381 Locking Spacer 313209391506 313209391506 313209391506 313209391506 313209391506 313209391506
457 Reinforcement (Drain Pan) 9362757003 9362757003 9362757003 9362757003 9362757003 9362757003
460-1 Pump Cover-A 9362775007 9362775007 9362775007 9362775007 9362775007 9362775007
460-2 Pump Cover-B 9362776004 9362776004 9362776004 9362776004 9362776004 9362776004
462 Top Cover Plate 9362806015 9362806015 9362806015 9362806015 9362806015 9362806015
464 Cabinet-A 9362800013 9362800013 9362800013 9362800013 9362800013 9362800013
465 Cabinet-B 9362801010 9362801010 9362801010 9362801010 9362801010 9362801010
467 Drain Port 9362786003 9362786003 9362786003 9362786003 9362786003 9362786003
468 Special Nut-A (Large) 313005446653 313005446653 313005446653 313005446653 313005446653 313005446653
469 Special Nut-B (Small) 313005446759 313005446759 313005446759 313005446759 313005446759 313005446759
472-1 Grille Reinforcement •T-A 9362738002 9362738002 9362738002 9362738002 9362738002 9362738002
472-2 Grille Reinforcement •T-B 9362739009 9362739009 9362739009 9362739009 9362739009 9362739009
472-3 Grille Reinforcement •T-C 9362740005 9362740005 9362740005 9362740005 9362740005 9362740005
472-4 Grille Reinforcement •T-D 9362741002 9362741002 9362741002 9362741002 9362741002 9362741002
472-5 Grille Reinforcement •T-E 9362742009 9362742009 9362742009 9362742009 9362742009 9362742009
474 Turbo Fan Assy 9362803014 9362803014 9362803014 9362803014 9362803014 9362803014
476-2 Special Washer 9362756006 9362756006 9362756006 9362756006 9362756006 9362756006
477 Bellmouth (B) 9362774000 9362774000 9362774000 9362774000 9362774000 9362774000
479 Float Switch 9703285004 9703285004 9703285004 9703285004 9703285004 9703285004
482 Pump Unit 9703125010 9703125010 9703125010 9703125010 9703125010 9703125010
484 Hook 9362736008 9362736008 9362736008 9362736008 9362736008 9362736008
487 Grille Hinge Wire 9362754002 9362754002 9362754002 9362754002 9362754002 9362754002
488 Drain Pan Plug 313005174654 313005174654 313005174654 313005174654 313005174654 313005174654
514 Control Box Cover 9362763004 9362763004 9362763004 9362763004 9362763004 9362763004
522 Joint Gear 9362772006 9362772006 9362772006 9362772006 9362772006 9362772006
540 Bypath Pipe-B 9363152005 9363152005 9363152005 9363152005 9363152005 9363152005
Part No.
AUT45ALA3W AUT45RLA3W AUT54ALA3W AUT54RLA3W
AUT36ALA3W
AUT36RLA3W
AUT45ALA3W
AUT45RLA3W
AUT54ALA3W
AUT54RLA3W
