– 30 –
When you order parts, please make a photocopy of this page
and fill the number of the parts in the “Order” column.
Ref. No. Ref. No.Description Description
Ord.
Q’ty
Ord.
Q’ty
IC1 IC µPD780024ACW-015 9700888017
IC2 IC NJM7805FA 0100462081
IC3,4 IC µPA2003GR 0100028041
IC6 IC PST600CMTR 0101461120
IC7 IC HU2001 9701651016
IC9 IC NJM7824FA 0100462098
IC10 IC NM93C46M8-X 0101622026
Q3,8,14 Xstr DTC124EKA 0000936033
Q5,6 Xstr 2SC2712 0000781053
Q9 Xstr 2SC4236 0000164016
Q10 Xstr 2SC1740S 0000699235
D1,23 Diode D1F60 0000208024
D2,3 Diode D2FL20U 0000906500
D6,7 Diode DA226U 0000625036
D11 Diode DAN202K 0000684019
D14 Diode D3SB60 0000689045
D18 Diode MTZJ5.1B 0000852166
D19 Diode 1SR139-600 0000353120
D20,21 Diode D1FL20U 0000746519
LED1~6 Diode SLR-325VC 0000813259
R1,3~5 Res. 4.7kΩ±5% 0200212906
R2 Res. 10kΩ±5% 0200231013
R7,8,11~13,23 Res. 1kΩ±5% 0200212746
~26,30~36,
54,55,77~80
R9,10,27,37~40, Res. 10kΩ±5% 0200213019
43,44,45,47,
49,50~52,56~
58,76
R17 Res. 38.3kΩ±1% 0201114575
R18 Res. 14kΩ±1% 0201114193
R19 Res. 6.65kΩ±1% 0201113806
R46 Res. Cement 3.3Ω±5% 0200244372
R59~62 Res. 10Ω±5% 0200230269
R67 Res. 1.5Ω±5% 0201107119
R68 Res. Metal 1W 330kΩ±5% 0200372136
R69 Res. 100Ω±5% 0200212500
R70 Res. 330Ω±5% 0200230627
R71 Res. 100Ω±5% 0200731506
R81 Res. Metal 2W 62kΩ±5% 0201107997
CJ26~28,37 Res. 0Ω 0200212012
C1,2 Cap. Plastic 0.22µF 0300304099
C3,4 Cap. Plastic 0.022µF 0301052098
C5 Cap. Elec. 25V 1000µF 0301196495
C6 Cap. Elec. 50V 1000µF 0301196822
C7,14,38~41, Cap. Ceramic 50V 0.01µF 0300311738
51~54,CJ35, 000000
CJ48
C8,29~31 Cap. Elec. 25V 10µF 0301192312
C10 Cap. Elec. 50V 100µF 0301192589
C12,13,17~19, Cap. Ceramic 50V 0.1µF 0300311752
36,42~46
C15,16,23~25 Cap. Ceramic 50V 1000pF 0300308509
C27 Cap. Elec. 450V 100µF 0300256060
C28 Cap. Plastic 4700pF 0300269091
C35 Cap. Plastic 50V 0.047µF 0300169339
C37 Cap. Elec. 50V 100µF 0301197560
C47 Cap. Elec. 25V 100µF 0301192350
C49 Cap. Ceramic 0.01µF 0300209127
X1 Ceramic Resonator 9701261017
EF0EC8384T4
K1~5,7 Relay JQ1-12V 9701316014
CR1,2,4,5 CR Absorber RPEL-121204-C 9701125012
T1 Switching Transformer 9703059018
ETS29AA175AC
VA1~3 Varistor TNR12G471K 0000038010
LF1 EMI Filter ELF15N005A 0400165040
SA1 Arrester RA-362M-V7-F 0600280154
F1 Fuse BET 6.3A-250V 0600222574
FH1,2 Fuse Holder PFC5000-0502 0500158072
SW1 Switch, Slide DSS804 9701393015
W1 Wire w/Terminal L=330 RED 9702929015
E Wire w/Terminal L=100 GRN 9702313012
HT1 Heat Sink PUE56-30 9703347016
CN2,15 Plug, PCB B2P3-VH-B-Y 0500011827
CN3 Plug, PCB B4P7-VH-B 0500011742
CN4 Plug, PCB 179844-1 0501121013
CN6 Plug, PCB 179844-4 0501121037
CN7 Plug, PCB B2P3-VH-B-C 0500011773
CN9 Plug, PCB B6B-XAKK-1-A 0501045425
CN10 Plug, PCB B3B-XASK-1-A 0501045029
CN11 Plug, PCB B6B-XASK-1-A 0501045050
CN13 Plug, PCB B2P-VH-B 0500011124
CN14 Plug, PCB B5P-SHF-1AA 0500006069
CN16 Plug, PCB B4P7-VH-B-R 0500011797
Part No. Part No.
[OUTDOOR UNIT]
CONTROLLER PCB ASSEMBLY (Ref. No.236)
AOT36ACF3L
AOT36RCF3L
AOT45ACF3L
AOT45RCF3L
AOT54ABF3L
AOT54RBF3L
