– 6 –
Models : AUT45ALA3W / AOT45ACF3L
: AUT54ALA3W / AOT54ABF3L
Refrigerant pipe
ø 19.05mm(3/4")
Refrigerant pipe
ø 9.53mm(3/8")
CAPILLARY TUBE
Charging valve
MUFFLER
COMPRESSOR
ACCUMULATOR
Charging valve
DRYER
OUTDOOR UNIT INDOOR UNIT
EVAPORATORCONDENSER
Models : AUT45RLA3W / AOT45RCF3L
: AUT54RLA3W / AOT54RBF3L
Refrigerant pipe
ø 19.05mm(3/4")
Refrigerant pipe
ø 9.53mm(3/8")
: COOL
: HEAT
Charging
valve
MUFFLER
HIGH
PRESSURE
SWITCH
COMPRESSOR
4-Way
Valve
ACCUMULATOR
Charging valve
DRYER
EXPANSION
VALVE
STRAINER
OUTDOOR UNIT INDOOR UNIT
EVAPORATORCONDENSER
