Fujitsu AUXG09KVLA - Fan Performance; Air Velocity Distributions

5. Fan performance
5-1. Air velocity distributions
¢
Model: AUXG09KVLA (4-way air outlet)
Measuring conditions
Fan speed Operation mode Ceiling mode
HIGH FAN STANDARD
Top view
Vertical airflow direction louver: Upward
4
3
2
1
0
1
2
3
4
Unit: m/s(m)
(m)
4 3 2 1 0 1 2 3 4
2
1
0.5
0.5
0.25
0.25
1
11
2
0.250.25
Side view
Vertical airflow direction louver: Upward
3
2
1
0
Unit: m/s(m)
(m)
4 3 2 1 0 1 2 3 4
2
1
0.5
0.25 0.25
0.5
1
Side view
Vertical airflow direction louver: Downward
3
2
1
0
Unit: m/s(m)
(m)
4 3 2 1 0 1 2 3 4
2
0.25 0.25
0.5 0.5
1 1
- 13 -
5-1. Air velocity distributions 5. Fan performance
CASSETTE TYPE AUXG09-22KVLA CASSETTE TYPE AUXG09-22KVLA
