6-2. Model: AOYG12KATA
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
COOLING
Pipe length (m)
5 7.5 10 15
Height difference H (m)
Indoor unit is higher than outdoor
unit *
1
15 — — — 0.903
10 — — 0.964 0.918
7.5 — 0.988 0.968 0.922
5 0.992 0.992 0.972 0.925
0 1.000 1.000 0.980 0.933
Indoor unit is lower than outdoor
unit *
2
-5 1.000 1.000 0.980 0.933
-7.5 — 1.000 0.980 0.933
-10 — — 0.980 0.933
-15 — — — 0.933
HEATING
Pipe length (m)
5 7.5 10 15
Height difference H (m)
Indoor unit is higher than outdoor
unit *
1
15 — — — 0.943
10 — — 1.010 0.943
7.5 — 1.000 1.010 0.943
5 1.000 1.000 1.010 0.943
0 1.000 1.000 1.010 0.943
Indoor unit is lower than outdoor
unit *
2
-5 0.995 0.995 1.005 0.939
-7.5 — 0.993 1.002 0.936
-10 — — 0.999 0.934
-15 — — — 0.925
6-3. Model: AOYG14KATA
NOTE:
Values mentioned in the table are calculated based on the maximum capacity.
COOLING
Pipe length (m)
5 7.5 10 15 20
Height difference H (m)
Indoor unit is higher than
outdoor unit *
1
15 — — — 0.953 0.950
10 — — 0.983 0.968 0.966
7.5 — 0.988 0.987 0.972 0.970
5 0.992 0.992 0.991 0.976 0.974
0 1.000 1.000 0.999 0.984 0.982
Indoor unit is lower than
outdoor unit *
2
-5 1.000 1.000 0.999 0.984 0.982
-7.5 — 1.000 0.999 0.984 0.982
-10 — — 0.999 0.984 0.982
-15 — — — 0.984 0.982
HEATING
Pipe length (m)
5 7.5 10 15 20
Height difference H (m)
Indoor unit is higher than
outdoor unit *
1
15 — — — 0.918 0.891
10 — — 0.981 0.918 0.891
7.5 — 1.000 0.981 0.918 0.891
5 1.000 1.000 0.981 0.918 0.891
0 1.000 1.000 0.981 0.918 0.891
Indoor unit is lower than
outdoor unit *
2
-5 0.995 0.995 0.976 0.914 0.886
-7.5 — 0.993 0.974 0.912 0.884
-10 — — 0.972 0.909 0.882
-15 — — — 0.900 0.873
- 66 -
6-2. Model: AOYG12KATA 6. Capacity compensation rate for pipe length and height difference
OUTDOOR UNIT AOYG09-22KATA OUTDOOR UNIT AOYG09-22KATA
