10. Electrical characteristics
Model name AOYG09KATA AOYG12KATA AOYG14KATA
Power
supply
Voltage V 230 ~
Frequency Hz 50 Hz
Max operating current *1 A 6.9 7.7 9.2
Starting current A 4.4 5.8 6.6
Wiring
spec.
*2
Circuit breaker current A 10 13
Power cable
mm
2
1.5
Connection
cable *3
Cross-sectional area
mm
2
1.5
Limited wiring length m 16 21
Model name AOYG18KATA AOYG22KATA
Power
supply
Voltage V 230 ~
Frequency Hz 50 Hz
Max operating current *1 A 10.1 11.6
Starting current A 7.9 8.8
Wiring
spec.
*2
Circuit breaker current A 13 16
Power cable
mm
2
1.5
Connection
cable *3
Cross-sectional area
mm
2
1.5
Limited wiring length m 21 26
*1: Maximum operating current is the total current of the indoor unit and the outdoor unit.
*2: Selected sample based on Japan Electrotechnical Standards and Codes Committee E0005. As
the regulations of wire size and circuit breaker differ in each country or region, select appropriate de-
vices complied to the regional standard.
*3: Limit voltage drop to less than 2%. If voltage drop is 2% or more, increase cable conductor size.
- 76 -
10. Electrical characteristics
OUTDOOR UNIT AOYG09-22KATA OUTDOOR UNIT AOYG09-22KATA

Fujitsu AUXG09KVLA Specifications

General

Brand	Fujitsu
Model	AUXG09KVLA
Category	Air Conditioner
Language	English
