Fujitsu D3240 User Manual

Internal connector s an d slots
USB 3.0
1 = 5V USB
2 = USB3_RX negative (P2)
3 = USB3_RX positive (P2)
4 = GND
USB3_TX negative (P2)
5 =
19
1
6 = USB3_TX positive (P2)
7 = GND
8 = Data negative (P2)
9 = Data positive (P2)
10 = FP Detect
11 = Data positive (P3)
12 =
Data negative (P3)
13 = GND
14 = USB3_TX positive (P3)
USB3_TX negative (P3)
15 =
16 = GND
17 = USB3_RX positive (P3)
18 = USB3_RX negative (P3)
19 = 5V USB
20 = Not connected
1
2
1 =
2 =
3 =
Audio Front Panel Connector
Mic Left
Mic Right
FP Present Detect
Headphone out Right
8 =
Analog GND
4 =
5 =
6 =
7 =
9 =
Jack Detect Mic
Analog GND
Key
Jack Detect Headphone
External connectors rear
1
2
1 = 5V USB
2 = 5V USB
3 = Data negative Port X
4 = Data negative Port Y
6 = Data positive Port Y
Data positive Port X
7 =
5 =
GND
8 = GND
9 = Key
10 = Not connected
Front panel
USB 3.0/
USB 2.0
DVI-D
USB 2.0
USB 2.0
Recovery inserted = The system starts
1
2
HD-LED
Recovery
Reset
Power
On/Off
Power LED
from USB stick and allows a BIOS recovery.
Details can be found in the BIOS manual.
Speaker -
Speaker +
PS2
D3230-A:
VG
A
DVI-D
SIO
FAN1
PCle x1
Buzzer*
PCle x16
Realtek
LAN 8111G
D3230-A/B:
USB3.0
D3240-B:
USB2.0
D3230-B:
Intel LAN
AFP
P1P0
SATA
Front
Panel Con.
D3240-B:
USB_1/2_x
FAN2
A, Slot 1
Audio
Descr.
Override
TPM*
TPM
Disable*
PCle x1
Audio
USB2.0
D3230-A:
USB_5/6_i
USB_3/4_x
P4P5
D3230-B
D3240-B:
SATA
Power
D3230-B
D3240-B:
Multirail
Power
Supply
Channel
Channel B, Slot 2
* Layout Prepared
12 V Power Rail
D3230-A:
Fujitsu
