Interfaces and connectors
The location of the interfaces and connectors of your mainboard is specified
at the beginning of the manual.
The components and connectors marked are not necessarily p resent on the mainboard.
External ports
The location of the external connections of your mainboard is specified at the beginning of the manual.
LAN port (RJ-45)
HDMI p ort
Audio output (Line out)
DP Displayport
Audio input (Line in)
PS/2 keyboard p ort
Socket typ e A black: Universal Serial Bus
–USB2.0
Socket type A blue: Universal Serial Bus –
USB 3.1 Gen 1
