Fujitsu ETERNUS DX200 S3 User Manual

Chapter 4 Connectivity Management
4.2 Host Group Management
ETERNUS Web GUI User’s Guide (Settings)
Copyright 2015 FUJITSU LIMITED P2X0-1270-13ENZ0
410
4 Click the [Done] button to return to the screen when starting this function in Step 1.
End of procedure
4.2.10 Add iSCSI Host
This function registers a new iSCSI host (HBA).
The following list shows the maximum number of hosts (*1) that can be registered for each ETERNUS DX
model.
*1: The total number of hosts irrespective of the interface types.
• ETERNUS DX60 S3
128
• ETERNUS DX100 S3/DX200 S3
1024
• ETERNUS DX500 S3/DX600 S3
1024
• ETERNUS DX8700 S3/DX8900 S3
8192
• ETERNUS DX200F
1024
Click the [Continue] button to continue registering FC hosts.
• This function is only displayed when the "Use "Add Host"" checkbox is selected for the "Function to Add
Host" field in "Web GUI Settings". This checkbox is not selected (this function is not displayed) by default.
Refer to "1.4.4 Setup Subsystem Parameters" (page 39)
for details.
• Note that this function does not create a host group. The ETERNUS DX also has a function that creates
new host groups to register hosts as its members. Refer to "4.2.2 Add iSCSI Host Group" (page 372)
for
details.
• Hosts that are registered with this function can belong to multiple host groups. However, only one LUN
group can be allocated to host and port combinations when configuring host affinity.
• Refer to "FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-" for each OS type to assign
an appropriate host response to the host that is to be registered. A host response has a recommended
patterns which has been prepared for each OS type. Refer to "Recommended patterns of host responses"
(page 472) for details.
If an appropriate host response is not configured to the host, the path may not be switched correctly or
the volume may not be recognized correctly.
• Unlike ETERNUS Web GUI, ETERNUS CLI can register two iSCSI hosts that have the same iSCSI name by
setting an IP address for one of these iSCSI hosts and by not setting an IP address for the other iSCSI host.
However, if iSCSI hosts are registered in the ETERNUS DX in this way, iSCSI hosts cannot be added using
ETERNUS Web GUI. Avoid this configuration when using ETERNUS Web GUI and ETERNUS CLI together. If
both iSCSI hosts already exist, use ETERNUS CLI to specify an IP address for the iSCSI host without the IP
address.

Fujitsu ETERNUS DX200 S3 Specifications

General

Model	ETERNUS DX200 S3
Category	Storage
Number of Controllers	2
Drive Types Supported	SAS, Nearline SAS
RAID Levels	0, 1, 5, 6
Power Supply	Redundant
Management Software	ETERNUS SF
Host Interfaces	Fibre Channel, iSCSI, SAS
Form Factor	Rack-mounted
