■Checking the information
1 Press the [Power] button on the operator panel.
The [Ready] screen is displayed on the LCD.
2 Press the [Menu] button.
The [Settings Menu] screen is displayed on the LCD.
3 Press the [] or [] button and select [Information], then
press the [Scan/Enter] button to confirm.
The [Information] screen is displayed on the LCD.
4 Press the [] or [] button to check the contents of the
information.
You can check the messages for replacing consumables/cleaning/
glass cleaning/regular maintenance.
When the message prompts replacing consumables/cleaning, the
corresponding counter that requires consumable replacement/
cleaning is highlighted. The counter will appear highlighted when:
z The page count after replacing the consumable reaches 95% of the
value configured in "Replacement Cycle of Consumables [Life
Counter Alarm Setting]" (page 181) in the Software Operation
Panel. (For brake roller/pick roller counters)
z The page count after cleaning reaches 100% of the value
configured in "Scanner Cleaning Cycle [Cleaning Cycle]" (page
181) in the Software Operation Panel. (Cleaning counter)
z The amount of remaining ink reaches below 33%. This is only
displayed when the imprinter is installed. (For ink counter)
M
e
nu
Scan/Enter
C
heck
Power
Stop/Clear
2 [Menu] button
3 []/[] button
[Scan/Enter] button
4 []/[] button
1 [Power] button
ATTENTION
[Information] can be selected only when there is a message for
replacing consumables/cleaning/glass cleaning/regular
maintenance.
To Next Page
