fi-7480 / fi-7460 CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS

Consumable Replacement Procedure

Pick Rollers Qty 2 Brake Roller Qty 1

Pick Roller Kit

Part Name

Part Number

Remarks

Pick-Roller-Kit

PA03670-0002

A shaft is not included in the Pick-Roller-Kit. When

replacing the pick roller, reuse the old Pick shaft.

Brake Roller Kit

Part Name

Part Number

Remarks

Brake-Roller-Kit

PA03710-0001

A shaft is not included in the Brake-Roller-Kit. When

replacing the brake roller, reuse the old brake shaft.

Brake Roller Assembly (with shaft) Pick Roller Assembly (with shaft)
