Fujitsu General ARXG36KHTAP - Capacity Table; Cooling Capacity

4. Capacity table
Capacity tables show each of following values calculated based on the outdoor temperature and the
indoor temperature, under given Airflow Rate (AFR):
For cooling capacity: Total Capacity (TC), Sensible Heat Capacity (SHC), and Input Power (IP)
For heating capacity: Total Capacity (TC) and Input Power (IP)
4-1. Cooling capacity
¢ Model: ARXG36KHTAP
AFR
m
3
/h
2,050
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 6.91 6.05 1.03 7.15 6.08 1.06 7.31 6.10 1.08 7.72 6.39 1.09 8.13 6.68 1.11 8.58 6.89 1.13 9.27 7.22 1.15
-10 6.76 6.03 1.26 7.00 6.06 1.29 7.16 6.08 1.31 7.56 6.37 1.33 7.96 6.66 1.35 8.40 6.87 1.37 9.07 7.19 1.40
0 6.47 6.00 1.70 6.70 6.02 1.74 6.86 6.04 1.77 7.24 6.33 1.80 7.62 6.62 1.83 8.05 6.83 1.85 8.69 7.15 1.89
5 6.42 5.97 1.75 6.64 6.00 1.79 6.80 6.02 1.82 7.17 6.30 1.85 7.55 6.59 1.88 7.98 6.80 1.91 8.61 7.12 1.95
10 6.36 5.95 1.80 6.59 5.98 1.85 6.74 5.99 1.87 7.11 6.28 1.91 7.49 6.56 1.94 7.91 6.78 1.97 8.54 7.10 2.01
15 6.26 5.85 1.86 6.48 5.88 1.90 6.62 5.90 1.93 6.99 6.18 1.96 7.36 6.46 1.99 7.77 6.67 2.02 8.39 6.98 2.07
20 9.44 7.86 2.42 9.77 7.89 2.47 9.99 7.91 2.51 10.55 8.29 2.55 11.10 8.67 2.60 11.73 8.95 2.63 12.66 9.37 2.69
25 8.98 7.65 2.50 9.30 7.68 2.56 9.51 7.71 2.60 10.04 8.07 2.64 10.57 8.44 2.68 11.16 8.71 2.72 12.05 9.12 2.78
30 8.53 7.44 2.58 8.83 7.48 2.64 9.03 7.50 2.68 9.53 7.85 2.73 10.03 8.21 2.77 10.60 8.48 2.81 11.44 8.88 2.87
35 8.07 7.24 2.66 8.36 7.27 2.72 8.55 7.29 2.77 9.02 7.64 2.81 9.50 7.98 2.86 10.03 8.24 2.90 10.83 8.63 2.96
40 7.55 7.03 2.78 7.82 7.06 2.85 8.00 7.08 2.89 8.44 7.42 2.94 8.89 7.76 2.99 9.39 8.01 3.03 10.14 8.38 3.10
46 6.93 6.78 2.93 7.18 6.81 2.99 7.34 6.83 3.04 7.75 7.16 3.09 8.16 7.48 3.14 8.61 7.72 3.19 9.30 8.09 3.26
¢ Model: ARXG45KHTAP
AFR
m
3
/h
2,550
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 8.51 7.31 1.68 9.23 7.68 1.72 9.71 7.92 1.74 10.20 8.25 1.77 10.68 8.58 1.79 11.12 8.74 1.79 11.79 8.97 1.79
-10 8.58 7.38 1.70 9.31 7.75 1.74 9.80 8.00 1.77 10.28 8.33 1.79 10.77 8.66 1.82 11.22 8.82 1.82 11.89 9.06 1.82
0 8.73 7.52 1.75 9.47 7.90 1.79 9.96 8.15 1.82 10.46 8.49 1.84 10.95 8.83 1.87 11.41 8.99 1.87 12.09 9.23 1.87
5 8.57 7.43 1.80 9.30 7.80 1.84 9.78 8.05 1.86 10.27 8.38 1.89 10.76 8.72 1.92 11.20 8.88 1.92 11.88 9.11 1.92
10 8.42 7.33 1.84 9.13 7.70 1.88 9.61 7.95 1.91 10.08 8.28 1.94 10.56 8.61 1.96 11.00 8.76 1.96 11.66 9.00 1.96
15 8.27 7.21 1.89 8.98 7.58 1.94 9.45 7.82 1.96 9.91 8.14 1.99 10.38 8.47 2.02 10.82 8.62 2.02 11.47 8.85 2.02
20 11.05 9.25 3.00 11.99 9.72 3.07 12.61 10.03 3.11 13.24 10.44 3.16 13.86 10.86 3.20 14.44 11.06 3.20 15.31 11.35 3.20
25 10.58 9.02 3.11 11.48 9.47 3.17 12.08 9.77 3.22 12.68 10.18 3.27 13.28 10.59 3.31 13.83 10.78 3.31 14.66 11.07 3.31
30 10.11 8.79 3.21 10.97 9.23 3.28 11.54 9.52 3.33 12.12 9.92 3.37 12.69 10.31 3.42 13.22 10.50 3.42 14.01 10.78 3.42
35 9.64 8.55 3.31 10.46 8.98 3.38 11.01 9.27 3.43 11.55 9.65 3.48 12.10 10.04 3.53 12.61 10.22 3.53 13.36 10.50 3.53
40 8.22 7.54 2.98 8.92 7.92 3.05 9.38 8.17 3.09 9.85 8.51 3.14 10.32 8.86 3.18 10.75 9.02 3.18 11.39 9.26 3.18
46 6.51 6.33 2.59 7.07 6.65 2.64 7.44 6.86 2.68 7.80 7.15 2.72 8.17 7.43 2.76 8.51 7.57 2.76 9.03 7.77 2.76
¢ Model: ARXG54KHTAP
AFR
m
3
/h
2,550
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 9.68 7.66 1.91 10.50 8.13 1.95 11.05 8.44 1.98 11.59 8.80 2.01 12.14 9.15 2.04 12.65 9.32 2.05 13.41 9.57 2.08
-10 9.67 7.66 1.92 10.49 8.13 1.96 11.04 8.45 1.99 11.59 8.80 2.02 12.14 9.15 2.05 12.64 9.32 2.06 13.40 9.57 2.09
0 9.66 7.67 1.94 10.48 8.14 1.98 11.03 8.45 2.01 11.58 8.81 2.04 12.13 9.16 2.07 12.63 9.33 2.09 13.39 9.58 2.11
5 9.49 7.59 1.99 10.30 8.06 2.03 10.84 8.37 2.06 11.37 8.72 2.09 11.91 9.07 2.12 12.41 9.23 2.14 13.15 9.48 2.16
10 9.32 7.51 2.04 10.11 7.97 2.08 10.64 8.28 2.11 11.17 8.63 2.14 11.70 8.98 2.17 12.18 9.14 2.19 12.92 9.39 2.22
15 9.16 7.39 2.10 9.94 7.84 2.14 10.46 8.15 2.17 10.98 8.49 2.21 11.50 8.83 2.24 11.98 8.99 2.25 12.70 9.23 2.28
20 12.24 9.59 3.76 13.27 10.18 3.84 13.97 10.57 3.90 14.66 11.01 3.96 15.35 11.46 4.01 16.00 11.66 4.04 16.96 11.98 4.09
25 11.72 9.35 3.89 12.71 9.92 3.97 13.38 10.30 4.03 14.04 10.73 4.09 14.70 11.17 4.15 15.32 11.37 4.18 16.24 11.68 4.23
30 11.20 9.10 4.02 12.15 9.66 4.11 12.78 10.04 4.16 13.42 10.46 4.22 14.05 10.88 4.28 14.64 11.08 4.32 15.52 11.37 4.37
35 10.68 8.86 4.14 11.59 9.41 4.24 12.19 9.77 4.30 12.80 10.18 4.36 13.40 10.59 4.42 13.96 10.78 4.46 14.80 11.07 4.51
40 9.10 7.59 3.73 9.88 8.06 3.82 10.39 8.37 3.87 10.91 8.72 3.93 11.42 9.07 3.98 11.90 9.24 4.01 12.62 9.49 4.06
46 7.21 6.07 3.24 7.83 6.44 3.31 8.23 6.69 3.36 8.64 6.97 3.41 9.05 7.25 3.46 9.43 7.38 3.48 10.00 7.58 3.53
