1. Specifications
Type
Duct
Inverter heat pump
Model name ARXG36KHTAP ARXG45KHTAP ARXG54KHTAP
Power supply 3N 400 V ~ 50 Hz
Power supply intake Outdoor unit
Available voltage range 342—457 V
Capacity
Cooling
Rated
kW 9.5 12.1 13.4
Btu/h 32,400 41,300 45,700
Min.—Max.
kW 2.8—11.2 4.0—14.0 4.5—14.5
Btu/h 9,600—38,200 13,600—47,800 15,400—49,500
Heating
Rated
kW 10.8 13.5 15.5
Btu/h 36,900 46,100 52,900
Min.—Max.
kW 2.7—12.7 4.2—16.2 4.7—16.5
Btu/h 9,200—43,300 14,300—55,300 16,000—56,300
Input power
Cooling
Rated
kW
2.86 3.53 4.42
Max. 4.12 4.88 5.23
Heating
Rated 2.48 3.37 3.89
Max. 4.53 4.74 4.83
Fan
HIGH
W
150 225 225
MED 90 135 135
LOW 60 90 90
QUIET 45 70 70
Current
Cooling
Rated A
5.50 6.60 8.00
Heating 4.90 6.40 7.20
Power factor
Cooling
%
75.0 77.2 80.4
Heating 73.9 76.6 78.4
EER Cooling
kW/kW
3.32 3.43 3.03
COP Heating 4.35 4.01 3.98
Moisture removal L/h (pints/h) 2.0 (3.5) 2.6 (4.6) 3.7 (6.5)
Maximum operating current *1
Cooling
A
10.5 14.0
Heating 10.5 14.0
Fan
Airflow rate
Cooling
HIGH
m
3
/h
2,050 2,550
MED 1,640 2,040
LOW 1,330 1,650
QUIET 1,070 1,430
Heating
HIGH 1,850 2,550
MED 1,640 2,040
LOW 1,330 1,650
QUIET 1,070 1,430
Type × Q'ty Sirocco fan × 3
Motor output W 375
Static pressure range Pa 30 to 200
Sound pressure level *2
Cooling
HIGH
dB (A)
36 39
MED 31 35
LOW 28 31
QUIET 26 29
Heating
HIGH 33 39
MED 31 35
LOW 28 31
QUIET 26 29
Sound power level
Cooling
dB (A)
64 67
Heating 63 69
Heat exchanger type
Dimensions (H × W × D)
mm
420 × 1,158 × 39.9
Fin pitch 1.4
Rows × Stages 3 × 20
Pipe type Copper
Fin type Aluminum
Enclosure
Material Steel sheet
Color ―
Dimensions
(H × W × D)
Net
mm
300 × 1,400 × 700
Gross 400 × 1,638 × 875
Weight
Net
kg
46
Gross 56
Connection pipe
Size
Liquid
mm (in)
Ø 9.52 (3/8)
Gas Ø 15.88 (5/8)
Method Flare
Drain hose
Material PVC
Size mm Ø 25 (I.D.), Ø 32 (O.D.)
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote control (Option)
Wired remote controller, Wireless remote controller, Mobile app*3 (FGLair
™
)
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
– Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
– Pipe length: 5 m, Height difference: 0 m. (Between outdoor unit and indoor unit.)
– Standard static pressure; 36 type: 47 Pa, 45 and 54 types: 60 Pa
• Protective function might work when using it outside the operation range.
• *1: Maximum operating current is the total current of the indoor unit and the outdoor unit.
• *2: Sound pressure level:
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• *3: Available on Google Play
™
store or on App Store
®
. Optional WLAN adapter is also required. For details, refer to the setting manual.
• This data is based on EN 14511 standard.
- 2 -
1. Specifications
DUCT TYPE
ARXG36-54KHTAP
DUCT TYPE
ARXG36-54KHTAP
