3-3. Setting of external input and output
• Indoor unit
Input
Connection point Function setting number 46 Function
Terminal
00 Operation/Stop mode 1
01 (Setting prohibited)
02 Forced stop mode
03 Operation/Stop mode 2
Output
Connection point Function setting number 60 Function
CN47
00 Operation status
01 to 08 (Setting prohibited)
09 Error status
10 Indoor unit fan status
11 External heater output
• External input and output PCB
Switch setting Input Output
Rotary
switch
SW2 Ex IN 1 Ex IN 2 Ex OUT 1 Ex OUT 2 Ex OUT 3
1
Edge Operation/Stop Not available
Operation
status
Error status
Indoor unit fan
status
Pulse Operation Stop
2
Edge*
Forced
thermostat off
Not available Error status
Indoor unit fan
operation
status
External heater
output
3 to 9, A (Setting prohibited)
B
Forced
thermostat off
Not available
Operation
status
Indoor unit fan
operation
status
External heater
output
C
Forced
thermostat off
Not available
Operation
status
Error status
External heater
output
D
Forced
thermostat off
Not available
Operation
status
Indoor unit fan
operation
status
Error status
NOTES:
• When the rotary switch is selected to “1", the operation of the terminal block input of the in-
door unit and the External input and output PCB input are the same. The operation content
depends on the setting of function setting number 46.
• *: The external input other than “Operation/Stop” is available only when the SW2 is set to
“Edge”.
3-3. Setting of external input and output
- (05-15) - 3. External input and output (For indoor unit)
