6-13. Unit status monitoring and the detected value indication
The wired remote controller can monitor the indoor and outdoor units' status and display the detect-
ed result as a relevant ID.
For details of the display method, refer to the Chapter of “Display Sensor Values” in the Installation
Manual of Wired remote controller (Touch panel).
The status can be monitored and displayed on the wired remote controller by assigning an arbitrary
ID. For available ID list, refer to the table below.
NOTE:
Operating time for each part cannot be reset when the part is replaced. Take notes of the
operating time before replacing to count the operating time of the replaced part.
Available Sensor ID
Sensor ID Item Unit Remarks
00: Indoor unit
00 000 Suction temp. 01: °C or °F
00 001 Room temp. 01: °C or °F
When the wired remote controller
thermistor is enabled, temperature of
the wired remote controller thermistor
is displayed.
00 002
Wired remote controller detected
temp.
01: °C or °F
00 003
Wireless remote controller detected
temp.
01: °C or °F
Temperature detected by wireless
remote controller
00 004 Discharge air temp. 01: °C or °F
00 005 Heat exchanger inlet temp. 01: °C or °F
00 006 Heat exchanger middle temp. 01: °C or °F
00 007 Heat exchanger outlet temp. 01: °C or °F
00 020 Fan rotation number 03: rpm
00 021 Fan 2 rotation number 03: rpm
00 022 Fan 3 rotation number 03: rpm
00 030 Expansion valve 05: pls
00 040 Operating pulse for right filter 05: pls
00 041 Operating pulse for left filter 05: pls
00 042 Operating pulse for filter brush 05: pls
00 050 Power relay for outdoor unit On/Off 08: On/Off 0: Off, 1: On
00 051 Float switch On/Off 08: On/Off
0: Off, 1: On (When the water level
rises)
00 052 Drain pump On/Off 08: On/Off 0: Off, 1: On
00 053
Solenoid valve for reheat operation
On/Off
08: On/Off 0: Off (Opened), 1: On (Closed)
00 054 Air cleaner status On/Off 08: On/Off 0: Off, 1: On
00 055 Limit switch 1 (For grille) On/Off 08: On/Off 0: Off, 1: On
00 056 Limit switch 2 (For right filter) On/Off 08: On/Off 0: Off, 1: On
00 057 Limit switch 3 (For left filter) On/Off 08: On/Off 0: Off, 1: On
00 070 Current sensor 09: A
00 080 Indoor unit total energized hours 11: h
00 081 Total filtering hours 11: h
00 082 Indoor unit fan total operation hours 11: h
00 083 Indoor unit fan 2 total operation hours 11: h
00 084 Indoor unit fan 3 total operation hours 11: h
00 090 Temperature sensor 12: %
00 095
Presence or absence detected by
human sensor
00: —
0: Absence, 1: Presence
—: Human sensor error or No human
sensor
6-13. Unit status monitoring and the detected value indication - (04-24) - 6. Various control
