Item no. Part no. Part name Service part
1 9383880001 Top panel assy ♦
2 9381013005 Protective net ♦
3 9375361013 Net rubber ♦
4 9900984038 Thermistor (Heat exchanger) ♦
5 9900727154 Thermistor assy ♦
6 9383607004 Thermo holder ♦
7 9383874017 Right panel sub assy ♦
8 9901031014 Heatsink thermistor ♦
9 9709684146 Inverter PCB ♦
10 9900634025 Reactor assy ♦
11 9901053016 Terminal ♦
12
9711431714 Main PCB (Service) (for 45 model) ♦
9711431721 Main PCB (Service) (for 54 model) ♦
13 313166024302 Drain cap ♦
14 9303029015 Drain assy ♦
15 9350255009 Base assy (Service) ♦
16 9383876011 Service panel sub assy ♦
17 9372171059 Emblem rear ♦
18 9383863011 Front panel assy ♦
19 9383604003 Blow grille ♦
20 9383882012 Left panel sub assy ♦
21 9383336003 Propeller fan ♦
22 9603733018 Brushless motor ♦
23 9383862014 Motor bracket assy ♦
24 9374420605 Condenser sub assy ♦
— 9711198020
Wire with connector
(P108 on Main PCB—Terminal)
♦
— 9711445001
Wire with connector
(P104-106 on Main PCB—W200-202 on Inverter PCB)
♦
— 9711446008
Wire with terminal
(P203-204 on Inverter PCB—Reactor)
♦
— 9711203007
Wire with connector
(P660 on Main PCB—P662 on Inverter PCB)
♦
— 9711204004
Wire with connector
(P661 on Main PCB—P663 on Inverter PCB)
♦
— 9711447012
Wire with terminal
(P400-402 on Inverter PCB—Compressor)
♦
— 9711212009
Wire with connector
(P650 on Inverter PCB—Fan motor)
♦
— 9711213006
Wire with connector (P770 on Inverter PCB—Wire with
connector [to Pressure switch]))
♦
— 9711214003
Wire with connector (Pressure switch—Wire with
connector [to Inverter PCB])
♦
a — Separate wall assy —
b — Control box unit —
3-1. Models: AOHG45KRTA and AOHG54KRTA - (02-7) - 3. Outdoor unit parts list
