En-3
PREPARATORY OPERATION
To set the operation mode
● Operation mode setting
● Room temperature setting
● Fan speed setting
OPERATION
Instructions relating to heating are applicable only to “HEAT & COOL MODEL” (Reverse Cycle).
To start/stop operation
CLOCK ADJUST
Press the timer mode (CLOCK
ADJUST) button for 2 seconds
or more. The time display on
the remote controller will flash.
2
DAY OFF
DAY
SU MO TU WE TH FR SA
Press the DAY button and select the current day.
A
appears around the selected day.
Press the set time buttons to set the current time.
Press repeatedly to adjust the current time in 1-
minute increments. Press and hold to adjust the
current time in 10-minute increments.
ex. Monday, 10:00 A.M.
Press again to end.
CLOCK ADJUST
1
3
4
AUTO COOL DRY HEATFAN
AUTO HIGH MED LOW
Temperature setting range
AUTO ............................................... 64 to 88 °F
COOL/DRY ....................................... 64 to 88 °F
HEAT ................................................ 60 to 88 °F
Lower Rise
Operation lamp
Air conditioner ON: Lit brightly
Air conditioner OFF: Not lit
Press the start/stop button.
Press the master control button to set the operation mode.
If DRY is selected, the fan speed will be set to AUTO.
Press the set temperature buttons to set the room temperature.
Press the fan control button to set the fan speed.
Set the current day and time
SU
MO
TU
WE
TH FR
SA
9368987046_OM_en.p65 25/8/05, 14:523
To Next Page
