18
- Locating the Controls and Connectors
Figure 5. LIFEBOOK notebook bottom panel
Bottom Components
The following is a brief description of your LIFEBOOK notebook’s bottom panel components.
Memory Upgrade Compartment
Your notebook comes with high speed Double Data Rate 3 Synchronous Dynamic RAM (DDR3
SDRAM). The memory upgrade compartment allows you to expand the system memory capacity of your
notebook, thus improving overall performance. See “Memory Upgrade Module” on page 63. Under
normal circumstances, it should not be necessary to open this compartmen
t.
Lithium ion
Air Vents
(multiple locations)
Memory
Upgrade
Compartment
Battery Bay
Battery Latch Battery Latch
