71
- Device Ports
HDMI Port
PRESSING THE [FN] + [F10] KEYS ALLOWS YOU TO CHANGE YOUR SELECTION OF WHERE TO SEND
YOUR DISPLAY VIDEO. EACH TIME YOU PRESS THE KEY COMBINATION, YOU WILL STEP TO THE NEXT
CHOICE. IF YOU ONLY HAVE AN EXTERNAL CRT CONNECTED, THE ORDER IS INTERNAL -> EXTERNAL
CRT ->
SIMULTANEOUS DISPLAY > INTERNAL DISPLAY.
I
F YOU ONLY HAVE AN HDMI DEVICE CONNECTED, THE ORDER IS: INTERNAL DISPLAY -> HDMI DISPLAY
->
SIMULTANEOUS DISPLAY -> INTERNAL DISPLAY.
I
F YOU HAVE EXTERNAL CRT AND HDMI DEVICES CONNECTED, THE ORDER IS: INTERNAL DISPLAY ->
EXTERNAL CRT -> SIMULTANEOUS INTERNAL AND EXTERNAL CRT -> HDMI DISPLAY - SIMULTANEOUS
INTERNAL AND HDMI DISPLAY -> INTERNAL DISPLAY.
The High-Definition Multimedia Interface
(HDMI) port is a digital audio/video interface
over which uncompressed streams can be
transmitted. HDMI is used to connect
compatible digital devices with your computer
(such as big-screen TVs and video recorders).
To connect an HDMI device:
1 Align the connector with the port opening.
2 Push the connector into the port until it is seated.
Figure 36. Connecting an HDMI device
