92
- Device Ports
External Video Port
The external video port allows you to
connect an external monitor or LCD
projector. In order to connect an external
video device, follow these easy steps:
1 Align the connector with the port opening.
2 Push the connector into the port until it is
seated.
3 Tighten the two hold-down screws,
located on each end of the connector.
Figure 39. Connecting an External Video Device
PRESSING THE [FN] + [F10] KEYS ALLOWS YOU TO CHANGE YOUR SELECTION OF WHERE TO SEND
YOUR DISPLAY VIDEO. EACH TIME YOU PRESS THE KEY COMBINATION, YOU WILL STEP TO THE NEXT
CHOICE, STARTING WITH THE BUILT-IN DISPLAY PANEL ONLY, MOVING TO THE EXTERNAL MONITOR
ONLY, FINALLY MOVING TO BOTH THE BUILT-IN DISPLAY PANEL AND AN EXTERNAL MONITOR.
