PLEASE NOTE: It is very important that you always press
the latch button to unlatch the display before opening it.
Failure to do so could result in damage to the latch and/or
system.
To open the display, press the latch button, located directly
below the latch (Figure 4). Note that the latch button may be
covered by the cover, but the cover is flexible enough to
unlatch the button through it. Be sure that the display is
unlatched before opening it.
Figure 4. Base cover latch button location
Latch
Latch button
location
Rubber Case FPC58- 2691-01.fm Page 3 Thursday, January 14, 2010 4:29 PM
