Be sure to turn OFF the power to the display and external equipment before making any connections.
No cables are supplied with the display for connection to external equipment. The type of cable to be used varies depending on the PC
model. Contact your dealer for more information.
Carefully check the terminals for position and type before making any connections.
Loose connectors can result in picture or color problems. Make sure that all connectors are securely inserted into their terminals.
These ferrite cores are used to attenuate undesired signals. Attach them correctly as shown in the following illustrations.
1 big ferrite core
When connecting the cord to the power input terminal, attach one of these ferrite cores to the cord and the cable near the terminal.
2 small ferrite cores
When connecting a cable to the external speaker output terminal, attach a ferrite core to the cable near the terminal.
ACCESSORIES
ATTACHING THE FERRITE CORES
Small ferrite
core (2)
Safety
Precautions
Large ferrite
core
Remote control AA battery (2) Power cableThis manual
ManualManual
Spacer (4)
Power Cord
Ferrite Core
