Fujitsu Plasmavision P42VCA10 - Page 9

E-9
English
4 Power input terminal
Connect this terminal to the power cable supplied with the display.
When connecting a cable, attach a ferrite core to the cable. (See P. E-13)
5 External speaker output terminal (EXT SP)
Connect this terminal to the optionally available speaker.
(When using other speaker than the optional one, use 4–16 Ω speaker.)
When connecting a cable, attach a ferrite core to the cable. (See P. E-13)
* See the speaker instruction manual for more information.
* P42VCA11/P42HCA11/P50XCA11/P42VCA21 only.
6 Sound 1 input terminal (AUDIO1 INPUT)
7 Sound 2 input terminal (AUDIO2 INPUT)
8 Sound 3 input terminal (AUDIO3 INPUT)
Connect this terminal to the sound output terminal of your VCR, etc. (See P.E-30 for the selection of audio input for video input.)
* This terminal is not available for P42VCA10/P42HCA10/P50XCA10/P42VCA20.
9 RGB2 input terminal (RGB2 INPUT/BNC)
Connect this terminal to the PC’s display (analog RGB) output terminal.
0 RGB2 synchronization switch (SYNC SW TTL/ANALOG (75 Ω))
This switch is used to terminate horizontal (H) terminal and vertical (V) terminal, out of RGB2 input terminals, with 75 Ω .
TTL : Does not terminate.
ANALOG (75 Ω): Terminates.
A S-Video input terminal (S-VIDEO INPUT)
Connect this terminal to the S-video output terminal of your VCR.
B Video input terminal (VIDEO INPUT)
Connect this terminal to the video output terminal of your VCR.
