Fujitsu PRIMERGY RX200 S8 - Accessible Drives; Fibre-Channel Controller; Communication;Network

System configurator and order-information guide
PRIMERGY RX200 S8 Status 30-01-2014
Configuration diagram PRIMERGY RX200 S8
System unit (I)
board front side
Memories CPUs right side
Memory CPU1 Accessible drives (V)
(Channel A + B + C + D)
Bay for 5,25"x 0,5" SATA-DVD
Bank 1 (4 Modules)
Xeon 4C, 6C or 8C
Only with option 4x 2.5" HD
Bank 2 (4 Modules)
CPU incl. Heatpipe
Bank 3 (4 Modules)
Xeon 4C, 6C or 8C
Hard disk drives (VI)
Memory CPU2
CPU incl. Heatpipe
(Channel E + F + G + H)
Bank 1 (4 Modules)
Processor ( II )
Bank 2 (4 Modules)
Xeon 4C, 6C 8C, 10C or 12C
Bank 3 (4 Modules)
CPU with serial QPI
Interface and
Memory ( III ) 4 memory channels
rear side Option 8x 2.5" HD Option 4x 2.5" HD
incl. bay for DVD
1. PSU 2. PSU
Double Fan HD8
2.5"x1" SAS
Redundant
or SATA
power supply
Redundant Fans
option
HD7
2.5"x1" SAS
or SATA
HD6
SATA or SATA/SAS RAID 0/1 2.5"x1" SAS
support on-board
or SATA
Extension slots for HD5
Disk Array (G-VII and H-VII) 2.5"x1" SAS
SAS and SCSI Controller (X) or SATA
Fibre Channel Controller (XI)
Communication/Network (XII) HD4 HD4
2.5"x1" SAS 2.5"x1" SAS
or SATA or SATA
Slot 4: PCIe-3 x8
Internal slot for modular RAID-Controller HD3 HD3
2.5"x1" SAS 2.5"x1" SAS
Slot 3: PCIe-3 x8 (low profile, half length) or SATA or SATA
(170mm incl. bracket)
left slot from rear view HD2 HD2
2.5"x1" SAS 2.5"x1" SAS
Slot 2: PCIe-3 x8 (low profile, half length) or SATA or SATA
Dedicated for modular on-board LAN-Controller HD1 HD1
2.5"x1" SAS 2.5"x1" SAS
Slot 1: PCIe-3 x16 (low profile, half length) or SATA or SATA
(170mm incl. bracket)
right slot from rear view
all slots @CPU1
Key:
Included in basic unit or = Option
One CPU (first CPU) and one memory (first memory) has to be selected for an orderable basic unit.
8x 2.5" HDD bays option or 4 x 2.5" HDD bays option with SATA DVD option
3 riser cards (butterfly for x8 slots rear)
(170mm incl. bracket) white colored middle slot
Fujitsu PRIMERGY Server 3 of 28
