Fujitsu PRIMERGY RX200 S8 System Configurator And Order-Information Guide

System configurator and order-information guide
PRIMERGY RX200 S8 Status 30-01-2014
Start PRIMERGY RX200 S8
Section
I
Basic unit
System unit consisting of:
* 1U Housing without power supply modules
(PSU has to be configured min 1x)
* Fans
- Redundant and hot plug system double-fans 4x for 1 CPU / 6x for 2 CPU configuration (n+1 redundancy)
* SAS Backplanes for 4x or 8x 2.5" HDD
with cable connection to on-board or modular RAID Controller
* Drives / Bays
- 4x 2.5" SAS / SATA HDD or 8x 2.5" SAS / SATA HDD option
- 1 bay SATA DVD-ROM 0,5" height (option if 4x 2.5" HDD only)
* Integrated ServerView Diagnostics Technology ( Diagnosis LED`s ) for indication of internal
failed components
Systemboard D3302 with:
* Up to two Xeon DP CPU`s (Socket-R)
with 2 serial QPI links ( Quick Path Interconnect ) and four memory channels per CPU
First CPU has to be selected for an orderable basic unit,
* Chipset Intel® C600 Series (codenamed Patsburg)
* 4 PCIe slots
-2x PCIe-3 x8 (Low Profile cards)
-1x PCIe-3 x16 (Low Profile cards)
-1x PCIe-3 x8 internal for modular RAID controller only
* 24 memory slots for max. 1.536GB RAM DDR3 available
- Memory is divided into 12 DIMMs per CPU ( 4 channels with 3 slots per channel )
Possible max. configurations are:
24x 64GB LRDIMM (eight rank modules) = 1536GB
16x 16GB RDIMM quad rank modules) = 384GB
16x 8GB UDIMM (dual rank modules) = 128GB (on special Release only)
First Memory ( one module ) has to be selected for an orderable basic unit per CPU
- Memory upgrade is possible module wise
- Memory mirrroring is supported with 2 identical modules in channel A+B/C+D CPU 1 or E+F/'G+H CPU 2
- Rank sparing mode is supported with min. 2x 1R/2R or 1x 4R modules for RDIMM or LRDIMM
- SDDC (Chipkill) is supported for RDIMMs (except x8 organisation) and LRDIMMs,
* Dual Port 10/100/1000 x4 PCI Express* Gigabit Ethernet Intel LAN controller Powerville on-board
* iRMC S4 (integrated Remote Management Controller) on-board server management controller with
dedicated 10/100/1000 Service LAN-port and integrated graphics controller.
The Service LAN-port can be switched alternatively on standard Gbit LAN port 1
* Graphics Controller integrated in iRMC S4 (integrated Remote Management Controller):
1600x1200x16bpp 60Hz, 1280x1024x16bpp 60Hz, 1024x768x32bpp 75Hz, 800x600x32bpp 85Hz,
640x480x32bpp 85Hz
(1280x1024x24bpp 60Hz only possible if local monitor or remote video redirection is off)
A
Fujitsu PRIMERGY Server 6 of 28
