RX2520 M1
Operating Manual 65
Starting up and operation
6.1.3 Controls and indicators for 3.5-inch variant
Figure 8: Front side of the 2.5-inch variant: indicators and controls
6.1.3.1 Control elements
1 Power-off indicator 5 NMI button
2 On/Off button / Power-on
indicator
6 Global Error indicator
3 ID button / ID indicator 7 CSS indicator
4 HDD/SSD activity indicator 8 Reset button
On/Off button
When the system is switched off, it can be switched on again by
pressing the On/Off button.
When the system is operating, pressing the On/Off button will
switch off the system.
V CAUTION!
Risk of loss of data!
I The On/Off button does not disconnect the server from the
mains voltage. To disconnect from the mains completely,
remove the power plug(s).
