Fujitsu PRIMERGY RX2520 M4

54 Operating Manual RX2520 M4
Hardware installation
Front side 3.5-inch HDD versions
Figure 3: Front side 3.5-inch HDDs (up to 8 HDDs)
Figure 4: Front side 3.5-inch HDDs (up to 12 HDDs)
Pos. Component
1 Front panel module
2ODD
3 Space for HDDs (depending on the configuration)
