System configurator and order-information guide
PRIMERGY RX300 S8 Status 2017-02-28
Independent Channel Mode allows all channels to be populated in any order. No specific Memory RAS features are defined
Requires min 1 memory Module per CPU
S26361-F3694-E1 Rank Sparing Mode Installation
BIOS Setup factory preinstalled to this mode. One Rank is spare of other ranks on the same channel. Spare Rank is not shown in System Memory.
For effective capacity within a channel, please have a look below.
Supported for RDIMM / LRDIMM only.
1x per CPU
Requires min 2x 1R/2R or 1x 4R modules per CPU
S26361-F3694-E2 Performance Mode Installation
BIOS Setup factory preinstalled for max. Performance, LV memory might be set to 1.5V operation. Four identical memory modules
will be equipped in one memory bank to achieve highest memory performance. All four modules are active and full capacity can be used.
Multiple of 4 identical modules to be configured per CPU
Mirrored Channel Mode Installation
BIOS Setup factory preinstalled to this mode. Four identical memory modules are always equipped in one memory bank to use the
Mirrored channel Mode. Only two modules contain active data, the remain two modules contain mirrored data
Supported for RDIMM / LRDIMM only.
Multiple of 4 identical modules to be configured per CPU
Minimum one memory module or order code per CPU = first memory
Unbuffered Memory (UDIMM) no SDDC (chipkill) support
- one DDR3 unbuffered ECC mem. Module, 1.35V
Choose up to 8 order codes per CPU
8GB (1x8GB) 2Rx8 L DDR3-1600 U ECC S26361-F3807-E515
Registered Memory (RDIMM) with SDDC (chipkill) support
- one DDR3 registered ECC mem. Module, 1.35V
Note 1)
1333MHz supported with up to 2DPC (8 modules/CPU) and 1.35V Max. DDR3 memory speed depends on the memory configuration
1600MHz supported with up to 2DPC (8 modules/CPU) and 1.5V (No of mem modules per channel) as well as on the CPU type.
Choose up to 12 order codes per CPU The memory channel with the lowest speed defines the speed
4GB (1x4GB) 1Rx4 L DDR3-1600 R ECC S26361-F3781-E514
of all CPU channels in the system, also for the channels of the
8GB (1x8GB) 1Rx4 L DDR3-1600 R ECC S26361-F3781-E515 second CPU if configured.
16GB (1x16GB) 2Rx4 L DDR3-1600 R ECC S26361-F3781-E516 For real memory speed (depending on memory type / population),
Registered Memory (RDIMM) with SDDC (chipkill) support please check the spreadsheet "Memory speed" below
8/12x per - one DDR3 registered ECC mem. Module, 1.5V
CPU, max. 1866MHz supported with up to 2DPC (8 modules/CPU)
2/3 modules Choose up to 12 order codes per CPU
per channel 16GB (1x16GB) 2Rx4 DDR3-1866 R ECC S26361-F3793-E516
Registered Memory (RDIMM) no SDDC (chipkill) support
Note 2)
- one DDR3 registered ECC mem. Module, 1.5V Mix of memory modules is only possible within the same group
No mix with any other types of memory modules possible
1866MHz supported with up to 2DPC (8 modules/CPU)
Choose up to 12 order codes per CPU
8GB (1x8GB) 2Rx8 DDR3-1866 R ECC S26361-F3793-E515
Load Reduced Memory (LRDIMM) with SDDC (chipkill) support
- one DDR3 load reduced ECC mem. Module, 1.35V
Choose up to 12 order codes per CPU
32GB (1x32GB) 4Rx4 L DDR3-1600 LR ECC
64GB (1x64GB) 8Rx4 L DDR3-1333 LR ECC
S26361-F3783-E518
Load Reduced Memory (LRDIMM) with SDDC (chipkill) support
- one DDR3 load reduced ECC mem. Module, 1.5V
1866MHz supported with up to 2DPC (8 modules/CPU)
Choose up to 12 order codes per CPU
32GB (1x32GB) 4Rx4 DDR3-1866 LR ECC S26361-F3848-E517
G
Effective Memory capacity / Rank Sparing Mode, 1 Channel populated
