Fujitsu PRIMERGY RX300 S8

System configurator and order-information guide
PRIMERGY RX300 S8 Status 2017-02-28
K
Section
VII
Modular Raid 0/1, Raid5 for SAS or SATA HD`s. On-board Controller for max. 4x 2.5" SATA or SAS HD`s
On board SATA Controller with 3 Gb/sec and up to 4x 2.5" SATA HDDs (no additional controller required)
For up to 4x 2.5" SAS HDDs with RAID 0/1 functionality a Patsburg Upgrade Kit is required
For all other HDD configurations a modular RAID-controller is required
Following optional onboard SAS RAID can be selected for 4x2.5" HDDs or one SAS Tape device
S26361-F3674-E1
Onboard 4 port SAS Controller
LSI
Patsburg B
RAID 0, 1 & 10
no controller cache
SAS 1.0 (3Gb/sec)
4 internal ports
PCIe x4
no PCI slot required
max. 1x per system
For more than 4 hard disks or 6 Gb/sec one of the following modular RAID-controllers is required
Modular Raid 0/1 controller with IME support for SAS/SATA
This RAID controller supports max. 8 HDDs on internal SAS ports
Modular Raid 5 controller for SAS/SATA
RAID levels 0, 1, 10, 5, 50, 6 and 60
The FBU is an option for the controller
are supported.
which can be used once per controller.
This RAID controller supports max. 16 HDDs
If the FBU option has been choosen, the
combined with internal SAS expander
TFM Module is needed once per FBU.
S26361-F3554-E8 S26361-F3554-E512 S26361-F3669-E4
RAID Ctrl SAS 6G 8port internal RAID Ctrl SAS 6G 8port internal RAID Ctrl SAS 6G 8port internal
Based on chip LSISAS2008 Based on chip LSISAS2108 Based on chip LSISAS2208
LSI MegaRAID
LSI MegaRAID
LSI MegaRAID
no Cache, no BBU 512MB Cache with ECC 1GB Cache with ECC
RAID 0, 1 & 10
RAID 0, 1, 10, 5, 50, 6, 60 RAID 0, 1, 10, 5, 50, 6, 60
Support for 3Gb/s and 6Gb/s
optional BBU
optional FBU
SATA and SAS hard drives Support for 3Gb/s and 6Gb/s Support for 3Gb/s and 6Gb/s
PCIe x8 SATA and SAS hard drives SATA and SAS hard drives
Low-profile MD2 form factor PCIe x8 PCIe 3.0 x8
max. 1x per system
Low-profile MD2 form factor Low-profile MD2 form factor
max. 1x per system
max. 1x per system
S26361-F3257-E216 S26361-F3669-E670
Cache Battery Backup Unit RAID Advanced Software Options
with 16 cm cable set License Activation Key
max. 1x per Controller for CacheCade 2.0 and FastPath
for 1 Controller
1x
Lose delivery options
S26361-F3669-E100
S26361-F3669-L670 S26361-F3669-L100
TFM Module for FBU option
RAID Advanced Software Options TFM Module for FBU option
(flash and FBU control logic)
License Activation Key
max. 1x per Controller
for CacheCade 2.0 and FastPath max. 1x per Controller
for 1 RAID Ctrl S26361-F3669-xx
S26361-F3669-E125
S26361-F3669-L110
Flash Backup Unit
Flash Backup Unit
with 25cm cable set
with 25cm, 55cm, 70cm cable set
max. 1x per Controller
max. 1x per Controller
L
Fujitsu PRIMERGY Server 21 of 31
