Figure 8: Front - detailed view: control panel
ID card
You can pull out the ID card (see figure 7 on page 61) as far as it will go and
push it back in again.
The ID card contains various system information, such as the product name,
serial number, order number, MAC addresses and DNS name (in the Japanese
market, only the product name and the serial number).
1 ID button / ID indicator 6 3x USB connectors
2 Reset button 7 Video connector
3 NMI button 8 HDD/SSD activity indicator
4 On/Off button / Power-on
indicator
9 Global Error indicator
5 AC connected indicator 10 CSS indicator
