6.1.2 Rear of server
6.1.2.1 Global Error indicator, CSS indicator, ID indicator and button
Figure 10: Global Error indicator and CSS indicator, ID button and ID indicator
1 CSS indicator (yellow)
– Lights up yellow if a prefailure event was detected for a CSS
component that you can fix yourself (for reasons of precaution) with
the CSS concept.
– Flashes yellow if an error was detected that you can fix yourself with
the CSS concept.
– Does not light up when the system is OK.
If the event is still acute after a power cycle, the indicator is activated
after the restart.
The indicator also lights up in standby mode.
For more information on the CSS concept, see "Customer Self Service
(CSS)" on page 15.
