TX1310 M3 Operating Manual 47
6 Starting up and operation
V CAUTION!
Follow the safety instructions in chapter "Important information" on
page 25.
6.1 Access to the drives
Figure 4: Removing the side cover
Ê Pull up on the locking lever (1).
Ê Open the side cover (2).
Ê Remove the side cover (3).
I The following procedure is described in detail in the "FUJITSU Server
PRIMERGY TX1310 M3 Upgrade and Maintenance Manual".
Ê Remove the HDD cage cover by pulling it backwards beginning at its right
side (4).
