48 Operating Manual
TX1320 M1
Hardware installation
5.2.1 Positioning the server vertically
V CAUTION!
If the server is positioned vertically, the stabilizers must be attached!
The stabilizers must be attached in the correct direction (see figure 4 on
page 50).
Clipping the stabilizers together
Figure 2: Clipping the stabilizer together
Ê Clip the stabilizers together in the direction of the arrow as far as the marking
line (a).
a
