64 Operating Manual
TX1320 M1
Starting up and operation
6.3.1.1 Local diagnostic indicators
I In addition to local diagnostic indicators, CSS or Global Error LEDs
indicate, if the defective component is a customer replaceable unit or if a
service technician needs to be dispatched to replace the part.
Symbol Indicator Status Description
[HDD]]
HDD / SSD
error indicator
orange on
HDD / SSD, SAS / SATA
backplane or RAID controller
failure detected
[PSU]
PSU error
indicator
orange on
Hot-plug PSU module failure
detected
I Only available in redundant
PSU configurations.
[TEMP]
Temperature
error indicator
orange on
Operating temperature levels
above permitted limits
[CPU]
CPU error
indicator
orange on CPU prefailure event detected
[MEM]
Memory error
indicator
orange on Memory module failure detected
Fan error
indicator
orange on
Fan prefailure or failure event
detected
!
