TX1320 M1
Operating Manual 63
Starting up and operation
6.3 Controls and indicators
6.3.1 Front of server
Figure 13: Front side (indicators and controls)
1 HDD error indicator 9 Global Error indicator
2 PSU error indicator 10 HDD / SSD activity indicator
3 Temperature error indicator 11 Power-on indicator
4 CPU error indicator 12 On/Off button
5 Memory error indicator 13 NMI button
6 Fan error indicator 14 Reset button
7 ID indicator 15 ID button
8 CSS indicator 16 2 USB connectors
