60 Operating Manual
TX1330 M1
Starting up and operation
If the system is programmed to eject the media automatically, the
accessible drives must not be obstructed.
The drive cover is replaced and the server locked in the reverse order.
Figure 6: Removing the drive cover from the HDD cover
Ê Carefully pull out on the green release lever (1) and lift off the drive cover (2).
①
②
