64 Operating Manual
TX1330 M1
Starting up and operation
6.2.1.2 Control elements
Lock (only floorstand model)
The server can be locked to prevent access to the drives.
Symbol Button Function
On / Off button
This button is used to switch the server on or off.
I If the system is running an ACPI-compliant
operating system, the pressing the On / Off
button will performs a graceful shutdown.
NMI NMI button
This button is used to troubleshoot software and
device driver errors It can be pressed using the
end of a paper clip.
V CAUTION!
Use this button only if directed to do so by
qualified certified maintenance personnel!
RST Reset button
This button is used to reboot the system. It can be
pressed using the end of a paper clip.
V CAUTION!
Risk of data loss!
ID ID button
This button highlights the ID indicator on the front
and I/O panels for easy server identification.
