Operating Manual
TX1330
M2
St
arting up
and operation
6.2
Control elem
ent
s and indicator
s
6.2.1
Fron
t of th
e serv
er
Figure 7: Front panel
1
2x USB 3.0
6
Global Error indicator
2
Reset button
7
HDD activity indicator
3
NMI button
8
On/Off button / Power-on indicator
4
ID button / ID indicator
9
AC-
connected indicator
5
CSS indicator
59
61
