Model: ROG12KMCDN
Unit: mm
Side view
Side view
Front view
Bottom view Side view (Valve part)
Top view
580
19
109
353
799 68 13 290
33 30
632
20
330
Pitch of bolts
for installation
Pitch of bolts for installation
4-
M1
0 hole
Airflow
Drain port Ø42
37
120
184
399 180
2-2. Outdoor unit - (01-7) - 2. Dimensions
GENERAL
INFORMATION
GENERAL
INFORMATION
