Model: ROG14KMCDN
Unit: mm
Side viewSide view Front view
Airflow
600
109
353
330
Pitch of bolts
for installation
Pitch of bolts for installation
4-
M1
0 hole
Drain port Ø42
37
410
Bottom view Side view (Valve part)
119
184
194
13 315
20 18
82019 68
716
20
2-2. Outdoor unit - (01-8) - 2. Dimensions
