SCENICVIEW A17-3/A19-3
Adjusting portrait format
The monitor can be turned from the "wide format" (landscape mode) into the "high format" position
(portrait mode).
► Grasp the monitor with both hands on the right and left edge of the casing, move it into the
highest position and turn it clockwise until it is in the portrait position.
You must use corresponding software (pivot software) so that the screen display is also
shown in the portrait mode. This software is included in the delivery (CD-ROM) and must
be installed on your computer.
i
► In the OSD menu you have the option of switching the OSD manually from landscape mode
into portrait mode (see section "
Monitor settings using the OSD menu").
To reset the monitor to the landscape mode, the monitor must be turned counter-clockwise. The
OSD display can be reset again in the OSD menu.
Switching the monitor on/off
The ON/OFF switch at the front is used for switching the monitor on and off.
1 = Buttons for the OSD menu
(On-Screen-display)
2 = ON/OFF switch
3 = Power indicator
The buttons are to be pressed from the bottom upwards.
i
The power indicator (3) lights up blue when the monitor and computer are switched on. The power
indicator lights up orange when the monitor does not receive a video signal or is in the energy saving
mode. The power indicator goes off when the monitor is switched off.
14 A26361-K1146-Z120-1-7619, edition 1
