Technical data
USB Type-C 65 W mains adapter for the Tablet
PC with/without the keyboard
docking
Technicaldata
Primary
Nominal voltage
100 V to 240 V (automatic)
Nominal frequency 50 Hz to 60 Hz (automatic)
Maximum rated current 1.8 A
Secondary
Nominal power 65 W
Nominal voltage 20 V
Max. rated current 3.25 A
An additional main
s adapter or power cable can be ordered at an y time.
Keyboard dock (optional)
Electrical data
Protection class II
Ports
Docking port 7-pin
LAN port 1 x
Environmental conditions
Environment class DIN IEC 721
7K1
Mechanism class DIN IEC 72 1
7M2
Operating tem per atur e 5 °C .... 35 °C / 41 °F .... 95 °F
Temperature during transportation
-10 °C .... 60 °C / 5 °F .... 140 °F
Relative humidity
20 % ... 80 % (no condensation)
Operating height
up to 3048 m
94 Fujitsu
